The Remii Deep Series of built-in electric fireplaces has been designed to give you the maximum in flexibility in selecting a unit that perfectly suits your needs.

Remii DEEP electric fireplaces are rated for Indoor or Outdoor use.
The Deep Series gives you a 12” depth and multiple length options, as well as – Full Frame Viewing Area – giving you the ability to install your fireplace with your choice of finishing material built right to the glass for a “clean face” design or using the provided black metal surround. Your choice – your design!
The Deep 12” fireplace comes with Canyon Brown and Ocean Blue fireglass media.

Included Accessories

• Canyon Brown and Ocean Blue decorative media embers.

Key Features

• Flame Presentation: Three light strips allow for yellow, orange colored flames
• Hard-wire ready: Thermostat hard-wire ready
• Heater & Fan: Flame operates with or without heat
• Illuminate decorative media like never before with ambient canopy lighting in 13 colors
• Perfect for zone heating approx. 500 sq ft. | 5000 BTU
• Deep 12” comes with Canyon Brown and Ocean Blue fireglass media, and black steel surround that can be installed if preferred

Product Information

Product Features

• All models are rated for either indoor or outdoor use
• Multi-color Flame presentation – three light strips allow for yellow, orange, blue, violet and rose colored flames
• Ambient Canopy lighting in 13 colors
• DEEP models have 2 flame sets
• Approx. heating area 400-500 sq. ft.
• 2 Stage heater
• Hard wire ready
• Thermostat hard wire ready
• Flame can operate without heat
• Single remote control for flame, ambient canopy lighting & heater included
• Full frame viewing – unit allows for choice of finishing material to come right to glass
• Optional black steel surround comes in the box, it is up to you if you want to use it or not

Product Specifications

45"

BI-45-DE / 102745-DE
Volts	120 AC / 60 Hz
Watts	1465 max
No Heater	25 W
Motor Heater	19 W
Appliance Size – (inches)	52.6 X 14.49 X 25.2″
Appliance Size – (mm)	1336 X 368 X 640mm
Gross Weigh	112.44 lbs or 51 kgs
Plug Location	Left Side
Cord Length	70 7/8” or 180 cm
Rough Wall Opening	45″ x 25″ or 114.3 cm x 63.5 cm
BTU	5000

---

55"

BI-55-DE / 102755-DE
Volts	120 AC / 60 Hz
Watts	1465 max
No Heater	25 W
Motor Heater	19 W
Appliance Size – (inches)	62.6 X 14.49 X 25.2″
Appliance Size – (mm)	1590 X 368 X 640mm
Gross Weigh	132.28 lbs or 60 kgs
Plug Location	Left Side
Cord Length	70 7/8” or 180 cm
Rough Wall Opening	55″ x 2 5″ or 140 cm x 63.5 cm
BTU	5000



---

65"

BI-65-DE / 102765-DE
Volts	120 AC / 60 Hz
Watts	1465 max
No Heater	25 W
Motor Heater	19 W
Appliance Size – (inches)	72.6 X 14.49 X 25.2″
Appliance Size – (mm)	1844 X 368 X 640 mm
Gross Weigh	154.32 lbs or 70 kgs
Plug Location	Left Side
Cord Length	70 7/8” or 180 cm
Rough Wall Opening	65″ x 2 5″ or 165 cm x 63.5 cm
BTU	5000



---

Example Flame Colors

This is just a small sampling of the flame colors that can be achieved for all the Remii models, along with a variety of media.

Product Manuals

Spec Sheet

• Remii BI-45-DE-Specs
• Remii - BI-55-DE Specs
• Remii BI-65-DE Specs

Deep Series Installation Manual

Brochure

Outdoor Installation Instruction

Glass Tray Measurements
